GM033
74 In Stock
Price (3.5% OFF)
$32.50
$31.36
Buy 10 or more
Save an additional 5%
$29.79
per unit
SKU / Part Number
GM033
Stock Level
74 units
Programming Instructions
Follow these steps to program this key to the vehicle.
<strong>Step-by-Step Programming Instructions:</strong>
<strong>Be sure to review all programming steps before proceeding</strong>
<ol>
<li>Insert the original, already programmed key in the ignition and turn to the ON position without starting the car.</li>
<li>After 10 seconds, turn the key to the OFF position and remove the key.</li>
<li>Within ten seconds, insert the key to be programmed and turn to the ON position without attempting to start the car.</li>
<li>The security light will turn off once the key has been programmed. If your vehicle does not have a security light (04-07 Grand Prix, Bonneville, Impala) wait 10 minutes and 45 seconds to make sure the key has been programmed.</li>
<li>Repeat steps 1 through 5 if additional keys are to be programmed.</li>
</ol>
Build Instructions
Internal manufacturing and assembly notes.
Hitag2 7941E
RECEIVE
PROCEDURE:
- Visually inspect the emergency blade. Make sure it will lock and release correctly and is UN-CUT.
- Use a remote frequency transmit tester to verify button function.
- Using the iKey Clone - place prox on tool.
- Open KEY CLONE/Click OK to detect device/ click NO to new software
- Select magnifying glass to detect transponder. (May need to toy with position to get it to read.)
- Press the pages button to read out key data.
- The flip key is UNLOCKED if the status bar bottom right starts to increase and populates all the data sections on the left. Under Select Type TP should be PCF7941E.
- Flip key is LOCKED if status bar never moves and data on the left column is blank.
